 The bits on this page are not major enough to deserve their own page, but are handy little dudes to solve some common nuisance problems. I'll be adding more as I have time.

124 Emissions Air Injection Plugs

It’s very common to remove horsepower robbing emission air pumps from 124 twin cam motors and the corrisponding unsightly air injection rail down the center of the head. Once the rail is gone, there are four open holes in the center of the head that need to be plugged which will otherwise allow exhaust gasses to escape.

CLICK FOR LARGER IMAGE

I tried some the loose Fiat fasteners I had laying around and found that wheel bolts fit perfectly in the air injection holes in the head. I drove over the our local Home Despot to try to make a match with "more attractive" Allen headed hardware and found they only had 3 of the 4 plugs I'd need. I said, screw it - literally. I went back home, cut four lug bolts off with a recip saw to about 1/2 inch long section, smoothed the cut ends down on the bench grinder, then with the recip saw again, cut a slot across the top of each cut face - viola, emissions plugs! I screwed 'em in with a large screw driver and a little loctite on the threads. I’ve actually received compliments for the more retro look of my plugs.



124 Marelli Electronic Ignition Conversion

As I write elsewhere in the site, I remain a big fan of converting vintage Fiats to electronic ignition from the standard points style, mainly for reliability benefits and arguably hotter spark. So it is with my ’74 124 Coupe in which I run the later Marelli stock and it is very reliable. Performance increase? Hard to say, probably some. But not having to mess with points and starting at a flick of the key is performance increase enough for me.

CLICK FOR LARGER IMAGE

This ignition was stock on the '79 and later injected cars. I know many other people who are running it on their earlier carbed DOHC motors and I think this conversion is more common than the use of the after-market Crane ignition. They are fairly inexpensive, readily available from a number of sources including eBay. The simple swap out of the coil and dizzy can take less than 10 minutes. Unlike with the Crane ignition, it doesn't require gutting or any cobbled re-use of your points dizzy should you ever want to switch back.

CLICK FOR LARGER IMAGE

Two things about this conversion:

1) The distrubutor has a vacuum advance. Leave this disconnected as carbed cars have no "ported" fitting to properly run this feature. Simply set your timing at idle to 12-18 BTDC and it will work like a charm.

2) Some early cars will exhibit tachometer bounce with the Marelli electronic ignition. That is: the tachometer will bounce around, generally act flaky, and pretty much be useless. Marelli specifies the use of 0.68uf capacitor in-line on the tach wire to correct the problem. To read more about this go to my Tach Fix Page.

3) Before installation of a used electronic distributor, its a very good idea to replace the magnetic pick-up as a matter of course. Whether it being from the dizzy living near the heat of the exhaust manifold or just plain & simple old age, the external control wire gets stiff and brittle, but more, the two inner wires are know to fray and pull apart. Keeping the magnetic pick-up fresh (replace every two years or so) will ensure the very reliable service these units provide.

CLICK FOR LARGER IMAGE




The constructed adapter bracket positions the Addco bar so that its centerline (at the bracket) is the same distance from the body work as the stock bar. Also it compensates for the bar's incorrect geometry by locating the center bushing brackets further back. Thus the bar goes in, like the stock bar, without any preload on the bottom A-arm. I suspect I might have to replace the end brackets as Pierre did, but I'll let it be for now.

Updated 20 Feb 2005
